RiiO Sun II Series 3KVA 24Volt / 48Volts

TBB RiiO Sun 3KVA-M All-In-One Solar Inverter

All in One Solar Inverter; Transformer Based.

RiiO Sun is a powerful all in one solar inverter integrated with multiple functions, including a high-performance true sine wave inverter, a powerful battery charger, an MPPT charge controller, and a high-speed automatic transfer switch.

RiiO Sun all in one solar inverter can be used in multiple applications. With a simple setting, you can compose a DC coupling system, solar hybrid system or power backup system. Its distinguishing surge capability makes it capable of powering the most demanding appliances, such as fridges, freezers, water pumps and air-conditioners, etc.

Under the generator mode, with the function of power assist & power control, RiiO Sun can automatically adjust its charging current to protect the grid or the generator from overload. It can also work as the supplement source to the generator or grid once the temporary peak power appears.

Features:

–   Type of Inverter: All-in-one, transformer-based

–   Voltage: 24 V

–   Max. AC Output: 3KW

–   Max. Output Current: 32 A

–   Max. AC Charge Current: 60 A

–   MPPT Efficiency: 98 %

–   Max. efficiency: 91 %

–   Weight: 18 kg

–   Dimensions: 499 x 271 x 144 mm

–   Protection: output short circuit, overload, high battery voltage, low battery voltage, high temperature, input voltage out of range, input voltage current too high, fan block.
