LVTOPSUN LVTS-256200 5.12kWh Lithium Solar Battery
The LVTOPSUN LVTS-256200 is a wall-mounted lithium-ion battery designed for residential photovoltaic energy storage. With a nominal voltage of 25.6V and a capacity of 200Ah, it provides 5.12kWh of nominal energy for compatible solar systems.
The battery features an LCD button screen and CAN, RS485 and RS232 communication interfaces for integration with supported equipment. Its suitability depends on inverter compatibility, battery management requirements and the installation’s energy needs.
Technical Specifications
| Specification | Details |
|---|---|
| Model | LVTS-256200 |
| Brand | LVTOPSUN |
| Nominal voltage | 25.6V DC |
| Nominal capacity | 200Ah |
| Nominal energy | 5,120Wh (5.12kWh) |
| Charge current | 100A |
| Discharge current | 160A |
| Charge voltage | 28.4V |
| Discharge voltage range | 22.8V–28.4V |
| Installation | Wall-mounted |
| Display | LCD button screen |
| Communication | CAN, RS485, RS232 |
| Dimensions (W × D × H) | 580 × 430 × 230mm |
| Weight | 50kg |
| Working temperature | -20°C to 60°C |
Key Benefits
- 5.12kWh nominal energy: Provides storage for later use of solar-generated electricity.
- 200Ah capacity: Suitable for compatible low-voltage energy-storage systems.
- Wall-mounted design: Provides a fixed installation option.
- Communication interfaces: CAN, RS485 and RS232, subject to supported protocols.
- LCD screen: Provides a local interface for battery monitoring.
Potential Applications
- Residential solar energy storage
- Home solar backup systems
- Compatible off-grid installations
- Solar systems requiring a 25.6V battery bank
Compatibility and Installation
Confirm that the inverter supports a 25.6V battery and the battery’s communication protocol. Follow the manufacturer’s charge, discharge, temperature and installation limits. The stated operating temperature range should not be assumed to apply equally to charging and discharging unless confirmed by the official datasheet.
Buy from Solar Man Power Solutions Ltd
For pricing, availability and compatibility enquiries:
- Phone/WhatsApp: +254 712 172 222 / +254 784 323 222
- Email: info@solarman.co.ke
- Website: https://solarman.co.ke
- Location: Northern Bypass, behind Galana Energies, Village Inn Road, Marurui, Nairobi, Kenya
